Overview

The MityCAM-CSG14K features a high-performance CMOS image sensor from ams / CMOSIS. The camera is available with an AIA USB 3.0 Vision Interface (U3V), and a video output interface.

Combined with Critical Link’s software tools designed for our Arria 10 based processor card, the MityCAM-CSG14K makes sensor evaluation and product integration quick and easy. Critical Link also supports a board set version of the camera for customers designing their own mechanicals or managing other integrations; contact us for more details.

Specifications

Sensor Specification

Sensor	ams/CMOSIS CSG14K
Active Pixels	3856 (H) x 3600 (V)
Pixel Size	3.2um x 3.2um
Image Area	25.4mm (W) x 25.4mm (H)
Frame Rate (Global Shutter)	110fps, full rate
Dark Current @ 60C	32e-/s
Dynamic Range	72dB-Normal
Chroma	Mono or Color

System Noise

Read-out Noise

2.3 e¯

Data Acquisition Modes

Global Shutter

For longer exposures or synchronizing with an external shutter

On-board Processor (MitySOM-A10S)

CPU Engine	Intel/Altera Arria 10 SoC – Dual core ARM and up to 480KLE FPGA fabric
Full Featured SDK	Supports rapid application development

Mount

Full cameras feature a standard F mount lens, while the board set version allows quick and easy custom integration into your product. Please contact Critical Link for more information.

Environment

Temperature	0°C to +40°C
Humidity	<80% non-condensing

Electrical

Voltage

12 VDC

Software

MityCAM image acquisition can be done with MityViewer, Critical Link’s software solution for optimal throughput and complete functionality.

We recommend visiting the MityCAM wiki page on our engineering support site and registering for an account in advance of receiving your MityCAM. Once your registration is confirmed, you can download the latest version of our MityViewer software from the wiki page, which will be required to start capturing images.

Purchase

The following table lists off-the-shelf configuration options for the MityCAM-CSG14K. For shipping status, availability, and lead time of these or other configurations, please contact Critical Link.

Camera Model	Enclosure Type	Interface Option	Color/ Mono	Buy
CSG14K-UM-C-S	Body	USB 3 + Video output	Mono	Buy
CSG14K-UC-C-S	Body	USB 3 + Video output	Color	Buy
CSG14K-UC-X-S	Board Set	USB 3 + Video output	Color	Buy

Accessory Kit

The table below outlines an accessory kit for the MityCAM-CSG14K. This kit is required when evaluating the sensor or doing development, and is compatible with the camera body models listed above. It is not required for cameras that are being integrated into a working design.

Part Number	Kit Contents
80-001150	Nikon 50mm f/1.8 Lens Tripod I/O Cable USB 3 Cable Video Output Cable Power Supply

Find your local sales contact.

Contact Critical Link for product availability

Overview

The Canon 35MMFHDXS Evaluation kit features an ultra-high sensitivity 2.76 MP industrial CMOS image sensor from Canon. The sensor’s enormous 19µm pixels, which minimize noise and dark current and allow control over readout position and frame rate, make the 35MMFHDXS and LI3030 unique in capabilities among all other CMOS sensors for low light imaging. The camera is available with an AIA USB 3.0 Vision Interface (U3V), and a video output interface.

Combined with Critical Link’s software tools designed for our Arria 10 based processor card, the Canon 35MMFHDXS Evaluation Kit makes sensor evaluation and product integration quick and easy. Critical Link also supports a board set version of the camera for customers designing their own mechanicals or managing other integrations; contact us for more details.

Evaluation Kit Contents

The Canon 35MMFHDXS Evaluation Kit allows integrators and end users to assess sensor performance and provides assets for image system designers to help accelerate development time. The Evaluation Kit features a camera with a pre-installed 35MMFHDXS or LI3030 19µm, 2.76 MP CMOS sensor with raw data serial output via a USB 3.1 (Gen 1) interface. The evaluation kit has an open architecture design and gives developers the option to embed processing and software with the on-board ARM and FPGA*.

The 35MMFHDXS Evaluation Kit includes:

Evaluation camera with pre-installed sensor (mono, RGB, or RGB-NIR )
Accessory package for out-of-the-box operation (quick start guide, power supply, all necessary cables)
Embedded software to setup the sensor, acquire image data, and communicate over USB 3.1 interface with any USB 3 compliant UI
PC-based UI application available for download to communicate with the camera
Sensor board design files source code*
VHDL code for the FPGA*

*Source code and VHDL code only available upon request with an NDA

NOTE: A Lens is not included in this kit.

As the lens plays a critical role in any imaging system, it is imperative that a suitable lens is selected to properly evaluate sensor performance for your end application.

When selecting an appropriate lens, there are several key factors which must be considered: Lens Type, Lens Mount, Focal Length, Sensor Size, Resolving Power, and Aperture to name a few of the more important ones. Some of these factors are associated with your application, and some are directly tied to how the CMOS sensor will perform.

Applications

Defense
Astronomy
Scientific & medical imaging
Industrial R&D
Night Vision
Surveillance & security
“Big Science” telescopy
Neuroscience
Fluorescence imaging/microscopy
Biomedical imaging
Microscopy
Machine vision

Documentation

Canon Sensor Evaluation Kits Overview
Critical Link 35MMFHDXS Evaluation Kit Datasheet
Quick Start Guide
User Manual
GenTL Viewer Manual
Canon 35MMFHDXS CMOS Sensor Product Page
Canon LI3030 CMOS Sensor Product Page
MitySOM-A10S System on Module Product Page
Altera Arria 10 SoC Documentation
Additional documentation is available on the MityCAM wiki page of our engineering support site (account required for some downloads)
