MityCCD-H11501

Contact Critical Link for product availability

Overview

The MityCCD-H11501 camera features Hamamatsu’s S11501-1007S back-thinned, area scan CCD image sensor with enhanced near infrared (NIR) sensitivity. The sensor’s superior performance at wavelengths longer than 800 nm delivers advantages for photometric applications beyond the previous generation of CCDs. This sensitivity is enabled by the unique MEMS structure on the back of the sensor, created using Hamamatsu’s proprietary laser processing technology.

The MityCCD camera delivers all the features of the Hamamatsu sensor including high sensitivity, binning operation, high signal to noise and signal processing speed, with a built-in thermoelectric cooler. The camera is available in multiple OEM configurations.

Features

  • Enhanced NIR sensitivity
  • 1024 x 122 active pixels
  • Large pixel size: 24 x 24 micron
  • High quantum efficiency
  • Wide spectral response range
  • TE-Cooled to -15°C
  • On-board image processing with DSP and FPGA
  • Open and Enclosed body styles
  • MityViewer software for setup, acquisition, viewing, and data analysis

Applications

  • Raman Spectroscopy
  • Low-light Imaging Applications
  • Embedded Instrumentation
  • Portable Scientific Instrumentation
  • Astronomy
  • Industrial Inspection

Documentation

Specifications

Sensor Specification

Type Back-illuminated CCD
Pixel Size 24 um x 24 um
Image Area 24.56mm x 2.92mm
Pixel Array 1024 x 122
Well Capacity
320 k e¯ (typical – vertical)
Well Capacity
1000 k e¯  (typical – horizontal)
Dark Current
1.5 e¯/pixel/sec  (@ -15 °C)

System Noise

Noise (typ)
12 e¯ RMS @ 500 KHz

Data Acquisition & Binning Modes

Area Read
Full image and sub-area (any rectangular region of the CCD)
Full Binning
Standard CCD binning (all CCD rows summed in read-out register)
Partial Binning
Some rows summed in CCD and partial results summed in MityDSP
Area Mask Binning
Vertical and horizontal binning in MityDSP
Multiple Binning Patterns
Multiple Binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32MB)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -15 °C (from 20 °C ambient) +/- .1 °C

Mount

Environment

Ambient Temperature Range
0°C to +50°C
Humidity
< 80%, non-condensing
Storage Temperature Range
 -40°C to +65°C

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

MityCCD-H11501_Spectral_Response













Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions (Enclosed Body)
94mm x 101mm x 99mm  (3.71″ x 4.00″ x 3.90″)
Weight (Enclosed Body)
750g  (26 oz.)

Development Tools and Software

Purchase

Camera Model Body Style Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-H11501-1007-BS Open Frame 24.56 2.92 1024 122 Buy
MityCCD-H11501-1007-DS Enclosed Body 24.56 2.29 1024 122 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



MityCCD-SU256LSB / SU512LSE

Contact Critical Link for product availability

Overview

 Features



  • InGaAs sensor
  • Tall pixels: 50 x 500 micron
  • Available in 1.7 and 2.2micron wavelength ranges
  • TE-Cooled to -10°C

Applications

  • Embedded Instrumentation
  • Raman Spectroscopy
  • Low-light Imaging
  • Portable Scientific Imaging
  • Astronomy

Documentation

MityCCD Family-level Documentation

Specifications

Sensor Specification

Type InGaAs
Pixel Size 50um x 500um
Pixel Array
256 x 1 (MityCCD-SU256LSB)
512 x 1 (MityCCD-SU512LSE)
Array Length
12.8mm (MityCCD-SU256LSB)
25.6mm (MityCCD-SU512LSE)
Saturation Charge
5×106 e¯/pixel (typical – High Sensitivity Mode)
130×106 e¯/pixel (typical – High Dynamic Range Mode)
Dark Current
9×10³ e¯/pixel/sec  (typ. @ -10°C)

System Noise

Noise – High Sensitivity Mode
800 e¯ RMS @ 25KHz
Noise – High Dynamic Range Mode
10,000 e¯ RMS @ 25KHz

Data Acquisition & Binning Modes

Full Line
Read out a complete line from the sensor
Partial Line
Read out partial line by specifying start / stop pixel
Binning
Specify horizontal binning pattern in the MityDSP
Multiple Binning Pattern
Multiple binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32MB)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -10°C (from 20°C ambient) +/- .1°C

Mount

Environment

Temperature
0°C to +30°C
Humidity
<80% non-condensing

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

MityCCD-SU256LSB-SU512LSE-Spectral-Response















Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions
99mm x 100mm x 90mm  (3.92″ x 3.94″ x 3.54″)
Weight
750g  (26 oz.)

Development Tools and Software

Purchase

Camera Model Enclosure Type Spectral Range Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-SU256LSB-DAB Enclosed Body 1.7um 12.8 0.5 256 1 Buy
MityCCD-SU512LSE-DAB Enclosed Body 1.7um 25.6 0.5 512 1 Buy
MityCCD-SU256LSB-BAB Open Frame 1.7um 12.8 0.5 256 1 Buy
MityCCD-SU512LSE-BAB Open Frame 1.7um 25.6 0.5 512 1 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



MityCCD-H9973

Contact Critical Link for product availability

Overview

Features

  • Front-illuminated sensor
  • Enhanced IR sensitivity
  • No etaloning
  • Large pixel size: 24 x 24 micron
  • TE-Cooled to -15°C



Applications

  • Raman Spectroscopy
  • Low-light Imaging
  • Industrial Inspection
  • Semiconductor Inspection
  • Portable Scientific Imaging

Documentation

MityCCD Family-level Documentation



Specifications

Sensor Specification

Type Front-illuminated
Pixel Size 24 um x 24 um
Image Area Various – See Camera Models Above
Pixel Array Various – See Camera Models Above
Well Capacity
240 ke¯ (typical – vertical)
Well Capacity
480 ke¯  (typical – horizontal)
Dark Current
100 e¯/pixel/sec  (typ. @ 0 °C)

System Noise

Noise (typ)
TBD e¯ RMS @ 500KHz

Data Acquisition & Binning Modes

Area Read
Full image and sub-area (any rectangular region of the CCD)
Full Binning
Standard CCD binning (all CCD rows summed in read-out register)
Partial Binning
Some rows summed in CCD and partial results summed in MityDSP
Area Mask Binning
Vertical and horizontal binning in MityDSP
Multiple Binning Patterns
Multiple Binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32MB)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -15 °C (from 20 °C ambient) +/- .1 °C

Mount

Environment

Temperature
0°C to +50°C
Humidity
10% to 90% non-condensing

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

S9973 Spectral Response

Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions
98mm x 100mm x 90mm  (3.86″ x 3.94″ x 3.54″)
Weight
750g  (26oz.)

Development Tools and Software

Purchase

Camera Model Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-H9973-1007 24.576 2.976 1024 124 Buy
MityCCD-H9973-1008 24.576 6.048 1024 252 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



MityCCD-H9971

Contact Critical Link for product availability

Overview

Standard resolution economical front illuminated sensor with built in TEC.

Features

  • Front-illuminated sensor
  • Visible and near IR sensitivity
  • No etaloning
  • Large pixel size: 24 x 24 micron
  • TE-Cooled to -15°C

Applications

  • Raman Spectroscopy
  • Low-light Imaging
  • Industrial Inspection
  • Semiconductor Inspection
  • Portable Scientific Imaging

Documentation

MityCCD Family-level Documentation



Specifications

Sensor Specification

Type Front-illuminated
Pixel Size 24 um x 24 um
Image Area Various – See Camera Models Above
Pixel Array Various – See Camera Models Above
Well Capacity
300 ke¯ (typical – vertical)
Well Capacity
600 ke¯  (typical – horizontal)
Dark Current
10 e¯/pixel/sec  (typ. @ 0 °C)

System Noise

Noise (typ)
6.5 e¯ RMS @ 500 KHz

Data Acquisition & Binning Modes

Area Read
Full image and sub-area (any rectangular region of the CCD)
Full Binning
Standard CCD binning (all CCD rows summed in read-out register)
Partial Binning
Some rows summed in CCD and partial results summed in MityDSP
Area Mask Binning
Vertical and horizontal binning in MityDSP
Multiple Binning Patterns
Multiple Binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32 MByte)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -15 °C (from 20 °C ambient) +/- .1 °C

Mount

Environment

Temperature
0°C to +50°C
Humidity
10% to 90% non-condensing

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

S9971 Spectral Response

Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions
98mm x 100mm x 90mm  (3.86″ x 3.94″ x 3.54″)
Weight
750g  (26oz.)

Development Tools and Software

Purchase

Camera Model Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-H9971-0906 12.288 1.440 512 60 Buy
MityCCD-H9971-1006 24.576 1.440 1024 60 Buy
MityCCD-H9971-1007 24.576 2.976 1024 124 Buy
MityCCD-H9971-1008 24.576 6.048 1024 252 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



MityCCD-H10141

Contact Critical Link for product availability

Overview

High resolution Hamamatsu CCD sensor (up to 2048 x 512 pixels) featuring low noise, high quantum efficiency and built-in TEC. Camera is available in multiple OEM configurations.

Features

  • High resolution back-illuminated sensor
  • Small pixel size: 12 x 12 micron
  • High quantum efficiency
  • Low noise
  • TE-Cooled to -15°C

Applications

  • Raman Spectroscopy
  • Low-light Imaging
  • Industrial Inspection
  • Semiconductor Inspection
  • Portable Scientific Imaging

Documentation

MityCCD Family-level documentation:



Specifications

Sensor Specification

Type Back-illuminated
Pixel Size 12 um x 12 um
Image Area Various – See Camera Models Above
Pixel Array Various – See Camera Models Above
Well Capacity
75 ke¯ (typical – vertical)
Well Capacity
150 ke¯  (typical – horizontal)
Dark Current
5 e¯/pixel/sec  (typ. @ 0 °C)

System Noise

Noise (typ)
TBD e¯ RMS @ 500 KHz

Data Acquisition & Binning Modes

Area Read
Full image and sub-area (any rectangular region of the CCD)
Full Binning
Standard CCD binning (all CCD rows summed in read-out register)
Partial Binning
Some rows summed in CCD and partial results summed in MityDSP
Area Mask Binning
Vertical and horizontal binning in MityDSP
Multiple Binning Patterns
Multiple Binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32MB)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -15 °C (from 20 °C ambient) +/- .1 °C

Mount

Environment

Temperature
0°C to +50°C
Humidity
10% to 90% non-condensing

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

S10141 Spectral Response

Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions
98mm x 100mm x 90mm  (3.86″ x 3.94″ x 3.54″)
Weight
750g  (26oz.)

Development Tools and Software

Purchase

Camera Model  Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-H10141-1007 12.288 1.464 1024 122 Buy
MityCCD-H10141-1008 12.288 3.000 1024 250 Buy
MityCCD-H10141-1009 12.288 6.072 1024 506 Buy
MityCCD-H10141-1107 24.576 1.464 2048 122 Buy
MityCCD-H10141-1108 24.576 3.000 2048 250 Buy
MityCCD-H10141-1109 24.576 6.072 2048 506 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



MityCCD-H7031

Contact Critical Link for product availability

Overview

Standard back-thinned camera featuring high sensitivity, low etaloning, and a built-in thermoelectric cooler. Camera is available in multiple OEM configurations.

Features

  • Back-illuminated sensor
  • Large pixel size: 24 x 24 micron
  • High quantum efficiency
  • Wide spectral response range
  • TE-Cooled to -15°C

Applications

  • Raman Spectroscopy
  • Low-light Imaging
  • Industrial Inspection
  • Semiconductor Inspection
  • Portable Scientific Imaging

Documentation

MityCCD Family-level documentation:

Specifications

Sensor Specification

Type Back-illuminated
Pixel Size 24 um x 24 um
Image Area Various – See Camera Models Above
Pixel Array Various – See Camera Models Above
Well Capacity
320 ke¯ (typical – vertical)
Well Capacity
1000 ke¯  (typical – horizontal)
Dark Current
10 e¯/pixel/sec  (typ. @ 0 °C)

System Noise

Noise (typ)
12 e¯ RMS @ 500 KHz

Data Acquisition & Binning Modes

Area Read
Full image and sub-area (any rectangular region of the CCD)
Full Binning
Standard CCD binning (all CCD rows summed in read-out register)
Partial Binning
Some rows summed in CCD and partial results summed in MityDSP
Area Mask Binning
Vertical and horizontal binning in MityDSP
Multiple Binning Patterns
Multiple Binning patterns stored in memory and swapped in as directed on a cycle basis

On-board Processor (MityDSP)

CPU Engine
Floating-point DSP, FPGA, FLASH, SDRAM (up to 32MB)
Full Featured SDK
Supports rapid application development
Applications
Peak finding, signature analysis, general purpose computing, etc.

Cooling

Type
Thermo-electric to -15 °C (from 20 °C ambient) +/- .1 °C

Mount

Environment

Temperature
0°C to +50°C
Humidity
10% to 90% non-condensing

Electrical

Voltage
110V / 220V or 12-24 VDC

Quantum Efficiency

MityCCD-H7031 Spectral Response

Block Diagram

MityCCD-H7031-Block-Diagram



Interfaces

USB Supports USB 2.0
Ethernet
Supports full TCP / UDP stack over 10 / 100 Base T
Digital I/O
Supports external triggering and control of outboard devices

Mechanical

Dimensions
98mm x 100mm x 90mm  (3.86″ x 3.94″ x 3.54″)
Weight
750g  (26 oz.)

Development Tools and Software

Purchase

Camera Model Image Area Active Pixels Buy
Width (mm) Height (mm) Horizontal Vertical
MityCCD-H7031-0906 12.288 1.392 512 58 Buy
MityCCD-H7031-0907 12.288 2.928 512 122 Buy
MityCCD-H7031-0908 12.288 6.000 512 250 Buy
MityCCD-H7031-1006 24.576 1.392 1024 58 Buy
MityCCD-H7031-1007 24.576 2.928 1024 122 Buy
MityCCD-H7031-1008 24.576 6.000 1024 250 Buy

Find your local sales contact.

*Note: Contact Critical Link for ordering information.



Product Quote Engineering Support Inquiry General Contact Email Us
